Microtest 6370 LCR Meter

The Microtest 6370 LCR Meter delivers 0.05% basic accuracy across a 20 Hz to 5 MHz frequency range for precision measurement of inductance, capacitance, resistance, impedance, dissipation factor, quality factor, and ESR. Designed for both engineering characterization and production-line component inspection, the 6370 combines measurement precision with production throughput features including multi-bin sorting, handler interfaces, and programmable test sequences.

Measurement Parameters

Parameter	Range	Application
Inductance (L)	nH to kH	Inductors, transformers, chokes
Capacitance (C)	pF to F	Capacitors, ceramic, electrolytic, film
Resistance (R/ESR)	milliohms to megohms	Resistors, contact resistance, ESR
Impedance (Z)	Full complex impedance	Filters, resonant circuits, sensors
Quality Factor (Q)	Automated calculation	Inductor and capacitor Q characterization
Dissipation Factor (D)	Automated calculation	Capacitor dielectric loss measurement
Phase Angle (theta)	Degrees	Complex impedance phase analysis

Bin sorting with handler interfaces enables automated component grading on production lines, where passive components are measured, classified into tolerance bins, and sorted without operator intervention. Statistical analysis functions provide SPC data for trend monitoring and process control. Programmable test sequences allow multi-parameter testing at multiple frequencies in a single measurement cycle.

GSAS Micro Systems provides LCR meter selection guidance, fixture design, and handler interface configuration for Indian component manufacturers and incoming inspection operations.
