C-GANG-X Compact Gang Programmer

The Elprotronic C-GANG-X is a compact gang programmer providing a smaller-footprint alternative to the S-GANG for bench-scale production, prototype runs, and engineering labs where space is at a premium. Despite its compact form factor, the C-GANG-X retains the same 18+ silicon vendor MCU support, programming interface coverage, and programming features as its larger sibling.

Compact Form Factor, Full Capability

The C-GANG-X targets production environments where the full 8-site capacity of the S-GANG is not needed but the same multi-vendor flexibility and programming features are required. Software-configurable MCU family switching means a single C-GANG-X replaces multiple vendor-specific programming tools on the bench.

Specifications

Feature	Specification
MCU Vendors	18+ silicon vendors
Form Factor	Compact bench-top
Interfaces	JTAG, SWD, Spy-Bi-Wire, BSL, cJTAG, SPI, SWIM, UART, TPI, PDI, UPDI
Galvanic Isolation	Yes, on PC interface
Onboard Storage	1 image, 8 MB total
Standalone Operation	Onboard firmware storage, PC-free
Networking	Up to 64 programmers networked
Serialization	Auto-incrementing serial number injection
Quota Management	Quota Based Programming, 500 initial quota included, additional purchasable separately
Checksum Verification	Post-program per-site verification
Security Lock	Device security bit programming
MCU Switching	Software-configurable, no hardware changes
Software	GangPro (included)

Programming Features

• Networking: up to 64 programmers networked for large-scale deployments
• Per-site pass/fail reporting with independent error isolation
• Serial number injection with auto-incrementing
• Quota Based Programming: includes initial quota of 500 upon purchase; additional quota can be purchased separately
• Checksum verification on every programmed device
• Device security lock as part of the automated sequence
• Onboard storage: 1 firmware image, 8 MB total
• Production logging for per-unit traceability
• Software MCU switching: no hardware changes between device families

The C-GANG-X uses the same GangPro software platform as the S-GANG, ensuring consistent operation across Elprotronic gang programmers. Teams can scale from C-GANG-X prototyping to S-GANG volume production without changing software workflows or retraining operators.

Watch the Elprotronic C-GANG-X gang programmer introduction

GSAS Micro Systems provides the C-GANG-X with MCU-specific configuration, fixture design guidance, and production workflow optimization for manufacturing teams across India.
