# ECAD-MCAD Co-Design: Eliminating Late-Stage Mechanical Surprises in Compact Electronics

There is a particular kind of engineering frustration that occurs when a PCB design, electrically verified, signal-integrity validated, DFM checked, arrives at the prototype stage and does not fit in its enclosure. A connector interferes with a housing rib. A tall electrolytic capacitor collides with the enclosure lid. A heatsink clearance that looked adequate in 2D turns out to be marginal in three dimensions. The board edge radius does not match the enclosure pocket.

These problems share a common root cause: the electrical design and the mechanical design were developed in isolation, synchronised only through periodic file exchanges and review meetings. In compact electronics, which describes an increasing proportion of Indian product development, this sequential, file-exchange approach to ECAD-MCAD collaboration is no longer viable.

Siemens EDA addresses this through true bi-directional ECAD-MCAD co-design, built on open standards and supporting the multi-CAD reality of most engineering organisations.

The Cost of Late-Stage Mechanical Surprises

The financial and schedule impact of ECAD-MCAD integration failures is well documented but consistently underestimated in project planning.

A mechanical interference found at the first prototype review typically requires changes to either the PCB layout, the mechanical enclosure, or both. If the PCB must be modified, the change propagates through re-layout, re-verification, re-fabrication, and re-assembly, a cycle that consumes three to six weeks in a typical Indian product development timeline. If the enclosure must be modified, the change propagates through mould modification (for injection-moulded parts) or fixture modification (for machined parts), each with its own lead time and cost implications.

More insidiously, late-stage mechanical problems often force compromise solutions. A component is moved to a suboptimal electrical location to resolve a mechanical clearance issue. A heatsink is downsized to fit the available space, creating a thermal margin problem. A connector is relocated, requiring a cable redesign that was not in the original project plan.

These compromises accumulate across the product, degrading performance, reliability, and manufacturability in ways that are difficult to quantify but real in their impact.

True Bi-Directional Sync via IDX 5.0

The foundation of Siemens ECAD-MCAD co-design is the IDX (Incremental Design Exchange) format, version 5.0. Siemens initiated and co-developed this standard with ProSTEP iViP, and it has been adopted as an industry standard for ECAD-MCAD data exchange.

IDX 5.0 is fundamentally different from the file-exchange approaches (STEP export, IDF files, DXF board outlines) that most engineering teams use today. The key differences are as follows.

Incremental exchange. IDX communicates changes, not complete designs. When the mechanical engineer moves a mounting hole, only the mounting hole change is communicated to the electrical design, not a complete re-import that risks overwriting other changes. Similarly, when the electrical engineer adds a component, only the new component placement is communicated to the mechanical design. Bi-directional negotiation. IDX supports a propose-review-accept workflow. The mechanical engineer can propose a board outline change; the electrical engineer reviews the proposal, accepts it, modifies it, or rejects it with comments. This negotiation happens within the design tools, not through email or meetings. Rich data exchange. IDX carries not just geometry but also design intent: keepout areas, height restrictions, thermal zones, flex-bend regions, and component placement constraints. The mechanical engineer sees not just where components are, but why they are there, enabling informed decisions about enclosure modifications. Change tracking. Every exchange is logged with timestamps, authorship, and change descriptions. The full history of ECAD-MCAD negotiations is preserved, providing traceability for design reviews and regulatory submissions.

3D Interference DRC

With bi-directional synchronisation established, the next capability is automated interference checking. Xpedition provides 3D Design Rule Checking (DRC) that detects collisions between electronic components and mechanical structures.

The 3D DRC operates on the combined ECAD-MCAD model: component bodies (from the Valor Parts Library or custom 3D models), board geometry, and mechanical enclosure features. The check identifies physical interferences, a component body intersecting an enclosure wall, as well as clearance violations, a component that is technically clear of the enclosure but does not meet the minimum clearance requirement for assembly, thermal management, or serviceability.

For compact electronics, 3D DRC catches problems that are invisible in 2D:

• A component that clears the enclosure wall in the XY plane but interferes in Z due to the enclosure draft angle
• A through-hole component lead that extends below the board surface and interferes with a standoff or boss on the opposite side of the enclosure
• A flex cable routing path that collides with a structural rib when the flex circuit is folded into its installed position
• A heatsink that clears in static analysis but interferes during board insertion due to the assembly sequence

These are precisely the problems that surface at the prototype stage and consume weeks of schedule to resolve.

Multi-CAD Support

Engineering organisations rarely standardise on a single mechanical CAD platform. The mechanical team may use one tool, a client or partner may use another, and legacy designs may exist in a third. Siemens ECAD-MCAD co-design supports this multi-CAD reality.

NX (native integration). As Siemens’ own mechanical CAD platform, NX provides the deepest integration with Xpedition. The IDX exchange is fully embedded in both tools, and the bi-directional synchronisation operates with the complete feature set. Creo (PTC). IDX-based exchange with Creo is supported, enabling the propose-review-accept workflow between Xpedition and Creo mechanical designs. SolidWorks (Dassault Systemes). IDX exchange with SolidWorks supports the core co-design workflow, covering board outline, component placement, height restrictions, and interference checking. Fusion 360 (Autodesk). For teams using Fusion 360 for mechanical design, IDX exchange provides the synchronisation capability needed for ECAD-MCAD co-design.

This multi-CAD support means that the choice of mechanical CAD tool does not prevent ECAD-MCAD co-design. The IDX standard provides a common language regardless of the specific MCAD platform.

IC Packaging Co-Design

ECAD-MCAD co-design is not limited to board-level design. At the IC package level, Xpedition Package Designer integrates with NX for package-level mechanical verification.

IC package design involves mechanical constraints that are at least as demanding as board-level design: die attach, wire bond or flip-chip interconnect, substrate warpage, lid attach, underfill dispensing, and thermal interface material application. Each of these processes imposes geometric constraints that must be satisfied simultaneously with the electrical interconnect requirements.

Xpedition Package Designer handles the electrical aspects, die pad mapping, substrate routing, via allocation, power/ground distribution, while the NX integration provides mechanical verification of the package structure: stress analysis, warpage prediction, thermal simulation, and assembly sequence validation.

For Indian semiconductor design teams working on custom IC packages, whether for ASIC designs, SiP (System in Package) modules, or advanced packaging architectures, this integrated capability eliminates the gap between electrical package design and mechanical package verification.

Token-Based Access for Xpedition Standard Users

Siemens recognises that not every engineer needs full-time access to the complete ECAD-MCAD co-design capability. For teams using Xpedition Standard, the ECAD-MCAD co-design features are available as token-based add-ons.

This means a design team can allocate co-design capability to the engineers who need it, when they need it, without requiring enterprise-level licensing for every seat. For Indian design teams managing license costs across multiple projects, this provides a practical path to adopting ECAD-MCAD co-design without a large upfront commitment.

Indian Applications

Indian product development increasingly involves compact, mechanically constrained electronics where ECAD-MCAD co-design delivers direct value.

Automotive ECU Housings. India’s growing automotive electronics sector, driven by BS-VI emission control, ADAS development, and EV powertrain control, produces ECUs that must fit in defined mechanical envelopes within the vehicle. The PCB must meet electrical requirements while conforming to an enclosure designed for specific mounting points, connector positions, and thermal management features. ECAD-MCAD co-design ensures these constraints are satisfied during design, not discovered during vehicle integration. Medical Device Enclosures. Indian medical device manufacturers developing diagnostic instruments, patient monitors, and portable imaging equipment face enclosure constraints driven by ergonomics, sterilisation requirements, and regulatory standards. The PCB layout must account for display cutouts, button positions, battery compartments, and cooling paths that are defined by the mechanical design. Bi-directional co-design ensures that electrical and mechanical requirements are resolved together. Compact Consumer Electronics. India’s consumer electronics design sector, wearables, IoT devices, smart home products, produces increasingly miniaturised products where the PCB essentially defines the product form factor. In these designs, there is no meaningful separation between electrical and mechanical design; every component placement decision has mechanical implications and every enclosure feature has electrical implications. Defence Ruggedised Systems. Indian defence electronics must meet environmental requirements (MIL-STD-810, JSS 55555) that impose specific mechanical constraints: shock and vibration resistance, thermal management in sealed enclosures, EMI shielding effectiveness, and connector retention under stress loading. These requirements can only be satisfied through integrated ECAD-MCAD design where the board, enclosure, and interconnect system are designed as a unified assembly.

The Workflow in Practice

A practical ECAD-MCAD co-design workflow using the Siemens toolchain follows a concurrent, iterative pattern.

The mechanical engineer defines the initial enclosure concept: board outline, mounting points, connector positions, height restrictions, and thermal management features. This information is communicated to Xpedition via IDX.

The electrical engineer places components and begins routing within the mechanical constraints. When a constraint conflict arises, a component exceeds the height restriction, a trace route requires a keepout area modification, the conflict is communicated back to the mechanical engineer via IDX as a change proposal.

The mechanical engineer evaluates the proposal, modifies the mechanical design as needed, and returns the updated constraints. This cycle repeats, with decreasing scope and frequency, until both designs converge on a solution that satisfies all electrical and mechanical requirements.

The entire exchange history is preserved, providing a complete record of design decisions and trade-offs for design review and regulatory documentation.

---
