RYLR999

The REYAX RYLR999 is a dual-radio module combining Bluetooth Low Energy 5.0 and LoRa (Semtech SX1262) in a single package with dual UART interfaces. This combination addresses a common IoT architecture requirement: long-range data transmission over LoRa for sensor-to-gateway communication, and short-range Bluetooth for local device configuration, firmware updates, and commissioning via a smartphone or tablet. The dual-radio approach eliminates the need for two separate modules, reducing PCB area, BOM cost, and integration complexity.

Feature	Specification
LoRa Chipset	Semtech LoRa Engine
LoRa Frequency Range	820 to 960 MHz
LoRa TX Power	30 dBm
LoRa Sensitivity	-133 dBm
LoRa Transmit Mode Current	950 mA @RFOP = 30dBm Continuous
LoRa Receive Mode Current	15.5 mA
LoRa Sleep Mode Current	1.25 uA @AT+MODE=1
BLE RF Output Power	20 dBm
BLE Sensitivity	-104.9 dBm @ 125 kbps GFSK
BLE Frequency Range	2400 to 2483.5 MHz
BLE Transmit Mode Current	190 mA @20dBm
BLE Advertising Current	17 mA @BLE broadcast 100ms
Interface	Dual UART with independent AT commands
Antenna	Dual antenna ports (LoRa + BLE)
Certification	FCC, CE pre-certified
Operating Temperature	-40 to +85 C

The dual UART architecture keeps the LoRa and BLE interfaces independent, allowing the host MCU to communicate with each radio separately. This enables concurrent operation, the LoRa radio can transmit sensor data to a distant gateway while the BLE radio simultaneously accepts configuration commands from a technician’s smartphone. AT command firmware on both interfaces maintains the same ease of integration that characterizes all Reyax modules, requiring no RF expertise from the application developer.

Field-configurable sensor nodes, smart agriculture devices that need both long-range telemetry and local Bluetooth provisioning, industrial IoT equipment with smartphone-based commissioning workflows, and gateway devices that bridge BLE sensor networks to LoRa backhaul benefit from the RYLR999’s integrated dual-radio design. The module is particularly valuable for deployments in remote locations where technicians need to configure and diagnose sensor nodes on-site using a mobile device without disrupting the LoRa data link.

GSAS Micro Systems provides REYAX RYLR999 modules from Indian inventory with INR invoicing, along with application architecture guidance for dual-radio IoT deployments and antenna design consultation.
