PicoScope 9400A SXRTO Series

The PicoScope 9400A Series from Pico Technology is a family of Sampler-eXtended Real-Time Oscilloscopes (SXRTO) that deliver high-bandwidth measurement up to 33 GHz across four simultaneous channels in a compact, USB-connected form factor. Unlike the sequential sampling architecture of the 9300 Series, the 9400A uses random interleaved sampling to reconstruct repetitive waveforms at an effective sample rate of up to 5 TS/s, combining the captured bandwidth of a top-tier sampling instrument with the multi-channel simultaneity and 12-bit vertical precision that signal integrity, telecom physical layer, and high-speed digital interconnect engineers in Indian R&D labs require. There is no mainframe, no plug-in module ecosystem, and no external sampling head, every channel in every model provides full bandwidth, full resolution, and independent trigger capability over USB 3.0.

9400A Series Specifications

Feature	Specification
Architecture	SXRTO, random interleaved sampling
Bandwidth (model dependent)	6 GHz / 16 GHz / 25 GHz / 33 GHz
Channels	4 analog, all simultaneous
Vertical Resolution	12-bit
Effective Sample Rate	Up to 5 TS/s
Clock Data Recovery	Optional on -CDR variants (clk rec for PAM4, NRZ serial data)
Connector	SMA (50 Ω)
Trigger	Edge, pattern, logic, NRZ/PAM4 data recovery
Interface	SuperSpeed USB 3.0
Form Factor	Compact desktop, no benchtop mainframe required
Software	PicoSample, acquisition, analysis, eye diagram, jitter, TDR
Power	External adapter

9400A Series Models and SKUs

The 9400A family spans eight SKUs, organized as four bandwidth tiers (6, 16, 25, 33 GHz) with an optional clock data recovery (-CDR) variant at each tier for engineers working with serial data streams, PAM4 signalling, and PCIe / USB / Ethernet compliance testing.

Model	Bandwidth	Clock Data Recovery	Typical Use Case
PicoScope 9404A-06	6 GHz	No	Mid-bandwidth signal integrity, USB 3.0, HDMI
PicoScope 9404A-06 CDR	6 GHz	Yes	PAM4 / NRZ serial data characterization at 5 Gb/s class
PicoScope 9404A-16	16 GHz	No	PCIe Gen 3/4, high-speed digital eye diagrams
PicoScope 9404A-16 CDR	16 GHz	Yes	Serial data recovery up to 16 Gb/s, jitter decomposition
PicoScope 9404A-25	25 GHz	No	10G/25G Ethernet compliance, PCIe Gen 5 analysis
PicoScope 9404A-25 CDR	25 GHz	Yes	PAM4 25 Gbaud recovery, stressed eye testing
PicoScope 9404A-33	33 GHz	No	Highest-bandwidth SI and telecom measurement
PicoScope 9404A-33 CDR	33 GHz	Yes	56G PAM4 / 33 Gbaud recovered clock measurements

Why the 9400A Series for Indian Labs

The 9400A replaces the expensive benchtop sampling oscilloscope for the vast majority of repetitive-signal characterization work, eye diagram analysis, jitter decomposition, PAM4 bit error rate correlation, TDR impedance profiling, and serial interconnect compliance testing, at a fraction of the cost and bench footprint of traditional sampling mainframes from Keysight DCA-X, Tektronix DSA8300, or Anritsu MP2000B. The 12-bit vertical resolution matters for precise amplitude measurements on NRZ and PAM4 signals where lower-resolution 8-bit instruments mask the signal detail that determines pass/fail on stressed eye tests. Four simultaneous full-bandwidth channels allow engineers to observe differential pairs, clock, and data concurrently without channel switching, essential for characterizing PCIe Gen 4/5 lanes, 10/25/100G Ethernet interfaces, and USB4 links where skew and jitter correlation between channels is the measurement.

Watch the PicoScope 9400A SXRTO Series introduction

The -CDR variants add integrated clock data recovery at every bandwidth tier, eliminating the external BERT clock source typically required for serial data analysis. For Indian teams designing SerDes transceivers, building PCIe or Ethernet compliance test benches, or qualifying high-speed optical transceivers, the 9400A CDR models collapse what used to be a two- or three-instrument rack into a single USB-connected box. GSAS Micro Systems provides the full 9400A range across India with model selection guidance, application engineering support for SI and telecom measurement setups, calibration logistics, and demo units for evaluation at our Bengaluru, Hyderabad, Chennai, Pune, Mumbai, and Delhi NCR facilities. Whether you need a 6 GHz 9404A-06 for USB 3.0 debug or a 33 GHz 9404A-33 CDR for 56G PAM4 characterization, we can arrange hands-on evaluation and local purchase support.
