Saleae Logic Pro 8

The Saleae Logic Pro 8 is the professional-tier 8-channel USB logic analyzer in Saleae’s Logic family. Shares the same internal architecture as the Logic Pro 16-500 MS/s digital sampling (USB 3.0, up to 4 channels at full rate), 50 MS/s analog at 12-bit resolution, 100 MHz digital bandwidth, selectable logic thresholds at +0.6 V / +0.9 V / +1.65 V, and an operating input range of −10 V to +10 V, packaged for designs that need 8 or fewer signals probed simultaneously.

For Indian semiconductor design houses, medical-device engineering teams, and sensor-module bring-up labs, the Logic Pro 8 is the right pick when the higher 500 MS/s sample rate, the 12-bit analog channels, and the selectable thresholds matter, but 16 channels would be overkill. The standard 8-channel coverage is enough for most single-bus debug sessions (I²C + chip selects + reset, or SPI + clock + chip selects + interrupt), and the 12-bit analog at 50 MS/s captures the rail behaviour under load that an entry-tier analyzer can’t see.

The Logic Pro 8 runs the same Logic 2 software as the rest of the line, free across Windows, macOS, and Linux; 23 built-in protocol analyzers plus 50+ community-shared decoders via the Logic 2 Marketplace (about 70+ in total); Python Automation API for headless CI captures; and the HLA framework for custom application-layer decoders.

In the box

Every Saleae Logic Pro 8 ships with:

• Logic Pro 8 analyzer pod
• 1× Wire Harness with hook-style test clips (8 channels)
• USB-C to USB-A cable (USB 3.0 SuperSpeed capable)
• Quick-start documentation

For automated CI/CD test racks and team labs, most India deployments add the 2x4 header cable so production fixtures don’t depend on flying-lead seating between runs, see Companion accessories below.

Companion accessories

• Saleae Wire Harness, Test Clips Set: extra hook-clip harnesses for spare-parts, multi-bench staging, or replacing a worn-out clip jaw
• Saleae Logic-to-Wires Cable (Flying Leads): direct labelled flying leads for breadboard, wire-wrap, and through-hole probing
• Saleae Logic 2x4 Header Cable (Gen 2): board-mounted Saleae-pinout debug header connections; the right cable for CI/CD and end-of-line test fixtures

Why GSAS for Saleae Logic Pro 8 in India

GSAS is Saleae’s authorized India engineering partner. The Logic Pro 8 ships through GSAS with on-site protocol-decode pre-sales engineering, Python and HLA scripting support, and India-side RMA handling across Bengaluru, Hyderabad, Chennai, Pune, Mumbai, and Delhi NCR. For the full spec sheet, see the Logic Pro 8 datasheet; for a one-page summary, see the Logic Pro 8 fact sheet. Request a Quote for pricing and lead time, or Contact us for a bench visit.
