Saleae Saleae Logic MSO 2×100
Mixed-Signal OscilloscopesEntry-tier 2-channel mixed-signal USB oscilloscope, 100 MHz analog bandwidth, 1.0 GS/s sampling, 12-bit Pro variant with 1B-sample memory, 8 to 20 digital channels. Buy in India from GSAS, authorized Saleae engineering partner.
Analog Channels
2
Analog Bandwidth
100 MHz
Analog Sample Rate
1.0 GS/s
Vertical Resolution
Std 9-bit (32 µV/LSB) / Pro 12-bit (4 µV/LSB)
Memory per Channel
Std 100 M pts / Pro 1 B pts
Calculated Rise Time
3.5 ns
Digital Channels
8 (expandable to 20 via Digital Probes)
Digital Sample Rate
1.0 GS/s
Digital Threshold
Selectable 0.6 V to 3.1 V
Interface
USB 3.0 (USB-A host) + USB-C PD 20V/1.5A (30W) power
Time Base Range
20 ns to unlimited
Input Impedance
1 MΩ || 16 pF
Max Input Voltage (SMB)
±30 V (derate at 20 dB/decade above 20 MHz)
Max Input Voltage (10:1 probe)
±300 V (derated above 5 MHz)
Operating Temperature
0°C to +40°C (pod) / 0°C to +25°C (power supply)
Protocol Decoders
23 built-in + 50+ community via Logic 2 Marketplace
Warranty
Standard manufacturer warranty
Country of Origin
Taiwan (HQ: South San Francisco, USA)
Overview
About Saleae Logic MSO 2×100
The Saleae Logic MSO 2×100 is the entry tier of the Logic MSO mixed-signal oscilloscope line, 2 analog channels at 100 MHz bandwidth, 1.0 GS/s analog sampling, calculated rise time 3.5 ns. 8 digital channels at 1.0 GS/s, expandable to 20 channels via Digital Probes.
The 2×100 is the right tool when a single SoC reset rail and a single bus need to come up together on the same screen, IoT sensor-node bring-up, single-rail switching regulator debug, or audio codec bring-up where one analog channel watches the rail and another watches the audio output. Standard variant: 9-bit ADC, 100 M sample points per channel. Pro variant: 12-bit ADC (4 µV/LSB), 1 B sample points per channel, the latter changes what’s catchable on a single trigger from “fast events” to “fast events plus 10-second drift”. Indian embedded teams in Bengaluru and Hyderabad running iterative bring-up cycles will recognise that difference.
The MSO 2×100 hosts over USB-C 3.0 with USB-PD power and runs the same Logic 2 software as every other Saleae device, 23 built-in protocol analyzers plus 50+ community-shared decoders (about 70+ in total), free across Windows / macOS / Linux, Python Automation API, and the HLA framework.
In the box
Every Saleae Logic MSO 2×100 kit ships with:
- MSO 2×100 pod (Standard or Pro variant, same hardware, software-unlocked memory/resolution)
- 2× 10:1 passive analog scope probes (100 MHz, for the 2 SMB analog inputs)
- 2× Digital Probes (8 digital channels total, expandable to 20 channels with additional Digital Probe orders)
- USB-C smart cable (pod → PC)
- USB-C PD power adapter
- Carrying case
- Quick-start documentation
Standard vs Pro: which variant?
The 2×100 hardware is identical across Standard and Pro; firmware enables higher analog resolution and deeper sample memory on Pro.
| Standard | Pro | |
|---|---|---|
| Analog vertical resolution | 9-bit | 12-bit (4 µV/LSB) |
| Analog sample memory | 100 M-sample / channel | 1 B-sample / channel |
| Digital channels (built-in) | 8 (expandable to 20) | 8 (expandable to 20) |
| Analog channels | 2 × 100 MHz | 2 × 100 MHz |
| Sample rate (analog) | 1.0 GS/s | 1.0 GS/s |
| Typical fit | IoT bring-up, single-rail regulator debug, audio-codec bring-up | Multi-second captures, drift / settling analysis, deeper trigger windows |
| Upgrade path | Software upgrade Std → Pro on the same hardware (contact GSAS for the licence) | - |
Pro turns the 2×100 from “fast events” into “fast events plus 10-second drift”, the difference matters if you’re chasing intermittent rail bounce or characterising start-up sequences. If you’re doing routine 2-channel mixed-signal debug, Standard is the value pick.
Companion accessories
- Saleae Wire Harness, Test Clips Set: extra hook clips for the bundled Digital Probes
- Saleae Logic-to-Wires Cable (Flying Leads): flying leads for breadboard digital-channel probing
- Saleae Logic 2x4 Header Cable (Gen 2): Saleae-pinout debug-header connections for production fixtures
Why GSAS for Saleae Logic MSO 2×100 in India
GSAS is Saleae’s authorized India engineering partner. The MSO 2×100 ships through GSAS with engineering support across Bengaluru, Hyderabad, Chennai, Pune, Mumbai, and Delhi NCR. Request a Quote or Contact us.
Videos
Saleae Logic MSO 2×100 in Action
Power Sequencing Verification with a Mixed-Signal Logic Analyzer
Saleae Logic 2 Tutorial: Capturing Data
Blog
Saleae Insights
Saleae Logic MSO: Standard or Pro? The India Buying Decision
Standard and Pro are the same Logic MSO hardware, the choice is 9-bit vs 12-bit analog resolution and sample memory per channel. Here is how Indian engineering teams should decide, model by model.
Best Logic Analyzer in India (2026): A Vendor-Neutral Buying Guide for Embedded Teams
Channels, sample rate, protocol decode, and streaming vs buffer, a vendor-neutral buying framework for choosing a USB logic analyzer or protocol analyzer in India, funnelling to the SKUs that actually fit your bus.
AI Data Centers in India: Test, Measurement & Memory Boom
AI is a hardware supercycle. Every AI rack has to be designed, brought up, powered, fed with memory, and kept alive, and each of those is a test, measurement and memory problem. Here is the full engineering toolchain behind the AI data center, mapped to what Indian teams can buy today through GSAS.
Related products
More from Saleae
All Saleae products →
Saleae Logic Pro 16
Flagship 16-channel mixed-signal USB logic analyzer, 500 MS/s digital, 50 MS/s analog at 12-bit, 100 MHz bandwidth, 23 built-in + 50+ community protocol decoders. Buy in India from GSAS, authorized Saleae engineering partner.
View Saleae Logic Pro 16 →
Saleae Logic MSO 4×200
Flagship 4-channel mixed-signal USB oscilloscope, 200 MHz analog bandwidth, 1.6 GS/s sampling, 12-bit Pro variant with 1B-sample memory, 8 to 20 digital channels. Buy in India from GSAS, authorized Saleae engineering partner.
View Saleae Logic MSO 4×200 →
Saleae Logic Pro 8
Professional-tier 8-channel mixed-signal USB logic analyzer, 500 MS/s digital, 50 MS/s analog at 12-bit, selectable thresholds. Buy in India from GSAS, authorized Saleae engineering partner.
View Saleae Logic Pro 8 →FAQ
Common questions about Saleae Logic MSO 2×100
What's the difference between Standard and Pro on the MSO 2×100?
When should I choose the 2-channel MSO over the 4-channel?
Does it replace a separate scope and logic analyzer?
What's in the box?
Can I drive captures from Python?
